Horizontal abdominal bench PTP 523-X.Dg

The horizontal abdominal bench is suitable for twisting, swinging the press, raising the legs when holding the horizontal bar and the "bicycle".

The construction will consist of support pillars made of steel pipes with a diameter of at least 89mm and a minimum wall thickness of 3mm, on clamps without welded joints. The horizontal bench surface for the development of the abdomen is to be made of HDPE (high density polyethylene) without toxic components with a multilayer structure of various colors, with a thickness of not less than 15mm. To avoid the penetration of water from precipitation, the pillars must be covered with plastic caps.

The metal elements need to be sandblasted and painted in an electrostatic field, in two layers with a minimum thickness of 100 microns to give them resistance to the external environment.

Materials: steel, plastic, HDPE.

Technical characteristics: General dimensions of the land, no less than: Length: 1628 mm, Width: 743 mm, Height: 795 mm.

In addition to the space occupied by the equipment, according to the regulations in force, a minimum impact area of ​​1.5 m-2.5 m will be provided.

The foundation of the complex will have minimum dimensions of LxWxH=400x400x700mm, and the foundation of the individual elements will have minimum dimensions of LxWxH=400x400x500mm.

Requirements for installation: To ensure safe and reliable operation, all supporting elements are to be deepened into the soil (ground) not less than 0.70m (0.50m – solitary elements) to increase rigidity, then following the concreting process (concrete BC 300). The assembly of the elements must exclude the possibility of their disassembly, without the use of special purpose tools.
